Head Support Adjustment
There are 12 head support positions.
1 - With harness loose (p.22), squeeze head
support button and move head support up or
down to desired position.
Release head support button and slide head
support slightly up or down until locked into
position. The head support will click when it locks.
CHECK that head support is locked on both
sides by pulling firmly up and down.
Recline Use
There are 8 recline positions.
2 - Positions 1–4 (BLUE) are for rear facing use with
children 5–50 lb (2.3–22.6 kg).
3 - Positions 1–4 (RED/PURPLE) are for forward
facing use with children 25–65 lb (11.3–29.4 kg),
and for booster use with children 40–120 lb
(18–54 kg).
4 - Press recline button (1) on either side of the
child restraint and tilt seat to desired recline
position (2).
Release recline button, and check that child
restraint is locked in desired recline position.
To change recline position after installation,
you MUST uninstall child restraint, select new
recline position, and then reinstall child restraint.
If infant's head falls forward, child restraint must
be reclined more. Use infant insert with infants
5–11 lb (2.3–5 kg) to improve recline angle.
4
3 2
1
1
2
3
4
1
2
4
5
30 EXEC
™
instructions
1
31EXEC
™
instructions
2
4
32
1
1
2
3
4
3
