Nuna PIPA LITE R User Manual

1
2
3
4
5
6
Shoulder Belts
1 - Tighten harness to fit snugly on
child’s shoulders. It is snug if
you cannot pinch a fold in the
strap horizontally.
2 - Harness straps must be at or
just below shoulders.
3 - To adjust shoulder harness
height, remove child and
loosen harness by pressing
the harness adjustment
button (1) while pulling on the
harness strap (2). The harness
adjustment button is located
inside the slot on the seat pad.
4 - Turn child restraint over and
remove one harness loop from
metal splitter plate.
5 - Pull loose ends of harness loop
out through slots and place in
correct slot.
6 - Repeat process for second
shoulder harness strap and
then re-attach harness to
splitter plate.
1
2
PIPA lite r instructions 27PIPA lite r instructions26

Nuna PIPA LITE R Specifications

General

Weight Capacity	4 to 32 lbs
Height Capacity	Up to 32 inches
Harness	5-point harness
Material	Aerospace aluminum
Safety Features	Side impact protection
Car Seat Base Included	No
Recline Positions	Multiple
Compatibility	Compatible with strollers
