The completely assembled child restraint is shown as
(10)
Recline Adjustment
Squeeze the recline adjustment button (11)-1, to adjust
the child restraint to the proper position. The recline
angles are shown as (11).
Please recheck the load leg position after reclining.
There are 7 recline angles for baby mode and 7
positions for toddler mode.
Baby Mode (Rearward Facing Mode)
Rearward Facing Child height 40cm-105cm/Child
weight≤18.5kg
Recline position Position 1-7
1 - Press the rotating button to rotate the seat facing
the rear of the vehicle. (12)(13)
Please recline the seat to be in positions 3 through
7 for ease of rotation.
2 - Rearward facing mode assembled as (13)
The ISOFIX connectors must be attached and
locked onto the ISOFIX anchor points. (13)-1
The load leg must be installed correctly with green
indicator. (13)-2
Height Adjustment
for Head Support and Shoulder Harnesses
Check that Shoulder Harness Straps are set at the
proper height.
Shoulder Harness Straps must be at a height nearest to
your childs shoulders (14), but not above the shoulder
line. (15)
If the Shoulder Harness Straps are not at the proper
height, the child might be ejected the child restraint if
there is a crash.
Squeeze the head support adjustment lever (16), while
pulling up or down on the head support until it snaps
into one of the 7 positions. The head support positions
are shown as (17).
Securing Child
After the child is placed into the seat, check whether
the Shoulder Harness Straps are at proper height.
1 - While pressing the adjustment button located at
the front of the child restraint, pull the two Shoulder
Harness Straps of the child restraint. (18)
2 - Unlock the buckle of the harnesses by pressing the
red button. (19)
3 - Fix the buckles on the both sides of seat to make
placing the baby more convenient. (20)
