3 - When installing the child restraint in the toddler
mode, do not use the infant insert.
4 - Fix the buckles on the both sides of seat to make
placing the baby more convenient. (20)
5 - Place the child into the child restraint and lock the
buckle. Please refer to. (22)
6 - Tighten the shoulder harness straps by pulling the
adjustment webbing. (27)
Make sure the space between the child and the
Shoulder Harness Straps is about the thickness of
one hand.
Detach Soft Goods
1 - Open the buckle, then remove the infant insert.
2 - Open the snaps. (28)
3 - Push the crotch strap through the crotch strap
opening. (29)
4 - Open the snaps on the main seat pad behind
shoulder harnesses. (30) Move the shoulder
harnesses behind the flap below the headrest. (31)
5 - Detach the hook and loop fasteners to remove the
shoulder belt cover. (32)
6 - Unfasten the elastic on the bottom of headrest to
remove the head support soft goods. (33)
7 - Remove the soft goods. (34)
To assemble winter and summer soft goods according
to reversed steps above.
Please keep the instruction manual in the storage
compartment at the bottom of the child restraint (35).
