4 - Use Infant Insert
Infant insert is for children’s protection. (21)
5 - Place the child into the child restraint and lock the
buckle. Please refer to. (22)
6 - Tighten the shoulder harness straps by pulling the
adjustment webbing. (23)
Make sure the space between the child and the
Shoulder Harness Straps is about the thickness of one
hand.
1
2
Detach the snaps on
the head support to
remove the head
portion of the insert.
We recommend
using the full infant
insert while the baby
is under 60 cm or
until they outgrow
the insert. The infant
insert increases side
impact protection.
Remove the head
support portion of
the infant insert
when the child’s
head no longer fits
comfortably.
Remove the body
portion of the infant
insert when the
infant’s shoulders no
longer fit comfortably.
The cushion can
be used separately
without being
attached to the
insert to bolster
the infant's back
for more comfort.
Remove the infant
insert cushion by
detaching the snaps
to allow more space
when the infant does
not fit comfortably.
Toddler Mode
(Forward Facing Mode)
Forward Facing
Child height 80cm-105cm/Child weight≤18.5kg
Recline position Position 1-7
NOT allowed to use forward facing before the age
of 15 month.
1 - Press the rotating button to rotate the seat facing
the vehicle's moving direction. (24)(25)
Please recline the seat to be in positions 3 through
7 for ease of rotation.
2 - Forward facing mode assembled as (25)
The ISOFIX connectors must be attached and
locked onto the ISOFIX anchor points. (25)-1
The load leg must be installed correctly with green
indicator. (25)-2
Securing Child
After the child is placed into the seat, check whether
the Shoulder Harness Straps are at the proper height.
(26)
1 - While pressing the adjustment button located at
the front of the child restraint, pull the two Shoulder
Harness Straps of the child restraint. (18)
2 - Unlock the buckle of the harnesses by pressing the
red button. (19)
