UAS Use
The UAS belt can be used instead of a vehicle belt
to install this child restraint. The lower anchor belt
MUST NOT be used forward facing if your child
weighs more than 18 kg (40 lbs).
The lower anchor belt can be used with the booster
from 18–54.4 kg (40–120 lbs).
The lower anchor belt and connectors are stored
under the UAS storage door.
Loosen and unbuckle harness, and unsnap seat
cover.
1 - Lift UAS storage door release button.
2 - Take out the lower anchor belt and connectors.
3 - Lengthen lower anchor belt for use by pressing
adjuster button while pulling on belt.
4 - For belt routing, see p.38 or p.46. To connect
lower anchor belt to lower anchors in vehicle,
press connector firmly onto lower anchor and
pull to check. Lower anchor belt MUST NOT
interfere with the vehicle seat belt.
5 - Remove all slack from lower anchor belt by
pulling loop at end of belt.
6 - To release lower anchor belt, press red button
on end of connector while pulling on belt.
Store lower anchors when not in use. Place
one lower anchor connector in each half of
the storage compartment. Fold excess belt
webbing into compartment. Belt MUST NOT
interfere with latching of storage door.
DO NOT cut the lower anchor attachment
strap. It permanently secures the lower anchors
to the child restraint.
32 33
2
4
3
5
6
1
