Nuna royl - Harness Mode Installation (Forward Facing)

EN EN
Harness Mode (forward facing)
Installation
At least 2 years old, 13.6–29.4 kg (30–65 lbs),
124.4 cm (49 in.) or less
Forward Facing Setup
Remove tether from storage and lengthen for use.
1 - Select desired forward facing recline position 1–4.
2 - Place child restraint forward facing in a compatible
vehicle seat with the bottom of the restraint
parallel to the vehicle seat bottom and the top of
the restraint contacting the vehicle seat back. The
leg rest MUST NOT be above the restraint seating
surface.
Loosen and unbuckle harness and retain with
magnetic buckle tongue holders.
3 - Fully raise headrest, lift seat cover, and open True
Tension
™
door.
Complete installation using your vehicle’s lap/shoulder
belt (p.40), the UAS belt (p.42), or a compatible
vehicle lap belt (p.44).
Move leg rest to desired installation position.
with UAS & tether
Forward Facing
with vehicle belt & tether
13.6 kg
(30 lbs)
18 kg
(40 lbs)
29.4 kg
(65 lbs)
DO NOT install with both the vehicle seat
belt and UAS.
1
2
3
4
38
1
2
3
39
