5.Operating instructions
The Safety Regulations must be observed during working with the automotive lift.
Read the safety regulations in chapter 4 carefully before working with the lift!
5.1 Positioning of the columns
• Every solid surface (concrete quality min C20/25) is suitable as installation-place.
•
Push the lever from the „neutral“ position to the „lifting“ position.
pic 1: Hand lever
• A - Move the hand lever several times in arrow-direction = The mobile column lift raise.
• B – Drive the Mobile column lift to the wheel or remove it.
pic 2: Positioning the column lift
• Lower the Mobile column lift. Pull the lever slowly. (see pic. 1)
