Operating Instruction and Documentation
MCS 5500 ND WIRELESS
- 9 -
3.Technical Information
3.1 Technical ratings
Capacity of one mobile column lift 5500 kg / 12000 lbs
Lifting time approx. 60 sec. with load
Lowering time approx. 65 sec. with load
Battery voltage 24V DC
Control rating 24 V
Power rating 2,1 kW
Motor speed 2600 rotation/min
Pump capacity 2,1 cm³/rotation
Hydraulic pressure approx. 220 bar with load
Pressure relief valve approx. 250 bar with load
Pressure relief valve (safety device) approx. max. 35 bar
Oil tank approx. 17 Liter
Sound level ≤ 75 dB(A)
Connection by customer (Battery charger) 110 / 220 V, 50 / 60 Hz
Fuse: mini 16 Ampere for 4 mobile column
(Pay attention to the tension of your state)
