13
TROUBLE POSSIBLE CAUSE SOLUTIONS
Excessive Vibration
• Pulp sticking to basket.
Basket dented or damaged, replace
basket. Basket Discolored (brown
color), clean basket thoroughly, soak
overnight in Clean Cut solution (See
directions on page 9).
Latches loose, tighten latches by
turning clockwise. Ensure even
tension on both sides.
Latch tension uneven; adjust to ensure
even tension on both sides.
Dull cutter plate, needs sharpening.
Cover rattles or latches come
undone.
• Loose latches.
Adjust and or tighten latch arms.
Pulp is too wet.
• Holes in basket are clogged.
Clean basket (see instructions for Clean
Cut).
• Dull cutter plate.
Sharpen cutter plate.
Pulp does not exhaust, but no
vibration problems.
• Clogged discharge opening.
Clean out pulp discharge tube.
MOTOR RESET PROCEDURE
The motor has an automatic safety shut-off to avoid overheating. When it detects an overload, it
automatically cuts off the power. It will not reset itself. There is a manual reset push button on the base of
the motor.
If your machine turns off while in use, allow the machine 15 minutes to cool.
To reset, switch OFF the machine and UNPLUG cord from outlet. Disassemble machine per instructions on
page 5. Turn the machine upside down so it is sitting on the castle. The red reset switch on the bottom of
the motor is accessible through the hatch on the base screen. Loosen the phillips screw and slide the hatch to
expose the switch. Firmly push on the red switch (you may hear an audible CLICK sound). Slide the hatch
door back into position and tighten the phillips screw. Turn the machine upright and reassemble per
instructions on page 6. If the machine stalls again, contact Nutrifaster at 1-800-800-2641.
