NUVE NF 200 - SECTION 2 TECHNICAL SPECIFICATIONS; 2.1 TECHNICAL SPECIFICATIONS TABLE; 2.2 OPTIONAL ACCESSORIES

5
SECTION 2
TECHNICAL SPECIFICATIONS
2.1 TECHNICAL SPECIFICATIONS TABLE
Technical Specifications
NF 200
Maximum speed
5.000 rpm
Maximum RCF
2.822xg
Tube capacity
12 x 15 ml
Control system
Programmable Microprocessor Control System
Speed set range
1.000-5.000 rpm
Speed set step
10 rpm / 1 rcf
Timer set range
1-99 min. and hold position
Timer set step
1 minute
Motor
Induction Motor
Power Supply
230 V, 50/60 Hz
Power Consumption
150 W
External Dimensions (WxDxH) mm.
280x360x260
Packet Dimensions (WxDxH) mm.
350x420x460
Net / Packed weight (kg)
12/16
2.2 OPTIONAL ACCESSORIES
G 03 012 Adaptor for 1.5/2 ml tubes, max tube dia 11 mm
G 03 014 Adaptor for 7 ml vacuumed/ non vacuumed tubes, max tube dia 13 mm
G0 3 015 Adaptor for 5 ml vacuumed/ non vacuumed tubes, max tube dia 13 mm
