NVIDIA BlueField-2 InfiniBand/Ethernet DPU User Guide 3
Figure 19. Image2021 8 11 8 44 35
Figure 20. Image2021 8 11 8 56 28
Figure 21. Image2021 8 11 8 44 3
Figure 22. Image2020 10 15 17 11 25
Figure 23. Image2020 10 15 17 17 1
Figure 24. Image2020 10 15 17 17 27
Figure 25. Image2020 10 15 17 18 53
Figure 26. Image2021 10 27 13 13 45
Figure 27. Image2022 6 6 10 13 24
Figure 28. Image2020 12 8 10 59 25
Figure 29. HHHL MBF2M355A VExOT Tall Bracket
Figure 30. HHHL MBF2M355A VExOT Short Bracket
Figure 31. Group4 Bracket
Figure 32. IB Group3 Bracket

Nvidia BlueField-2 InfiniBand Specifications

General

Processor	Arm Cortex-A72
Connectivity	InfiniBand, Ethernet
Security	Hardware Root of Trust, Secure Boot
Crypto Acceleration	Yes
Architecture	Arm
PCIe Interface	PCIe 4.0 x16
Security Acceleration	Yes
Network Acceleration	Yes
Network Interface	InfiniBand
Memory	16GB DDR4
Form Factor	PCIe
Product Type	DPU (Data Processing Unit)
Ethernet Speed	200Gbps
Storage	NVMe over Fabric support
Networking Features	RDMA, RoCE, SR-IOV
Cores	8x Arm A72 cores
