NVIDIA BlueField-2 InfiniBand/Ethernet DPU User Guide 52
For further instructions, please refer to the cable vendor documentation. Please
refer to the pinout description in External Power Supply Connector Pins .
7. Close the system case.
8. Install the networking cables. For instructions, please refer to Networking Cable
Installation.
Cables and Modules
Networking Cable Installation
1. All cables can be inserted or removed with the unit powered on.
2. To insert a cable, press the connector into the port receptacle until the connector is
firmly seated.
1. Support the weight of the cable before connecting the cable to the DPU card.
Do this by using a cable holder or tying the cable to the rack.
2. Determine the correct orientation of the connector to the card before
inserting the connector. Do not try and insert the connector upside down. This
may damage the DPU card.
3. Insert the connector into the DPU card. Be careful to insert the connector
straight into the cage. Do not apply any torque, up or down, to the connector
cage in the DPU card.
4. Make sure that the connector locks in place.
Note
To uninstall the DPU card, see Uninstall DPU.
Warning

Nvidia BlueField-2 InfiniBand Specifications

General

Processor	Arm Cortex-A72
Connectivity	InfiniBand, Ethernet
Security	Hardware Root of Trust, Secure Boot
Crypto Acceleration	Yes
Architecture	Arm
PCIe Interface	PCIe 4.0 x16
Security Acceleration	Yes
Network Acceleration	Yes
Network Interface	InfiniBand
Memory	16GB DDR4
Form Factor	PCIe
Product Type	DPU (Data Processing Unit)
Ethernet Speed	200Gbps
Storage	NVMe over Fabric support
Networking Features	RDMA, RoCE, SR-IOV
Cores	8x Arm A72 cores
