Front Fan Module Replacement
DGX-2 System DU-09224-001 _v09|5
3. Remove the failed front fan module by pressing on the tab and pulling on the handle.
4. Quickly insert the new fan module, observing that the handle release mechanism is facing
up and the rear connector is facing down.
CAUTION: Replace the fan module within 30 seconds to prevent overheating of the system
components.
