SN2700 Telescopic Rail Kit
There are two installation kit options:
Standard depth systems should be mounted using the standard rail kit.
Short depth systems can be mounted using either of the rail kits.
Kit Part Number Kit Legacy Part Number Rack Size and Rack Depth Range
930-9BRKT-00JD-000 MTEF-KIT-B Short: 17"-24" (43.1 to 61 cm)
930-9NRKT-00JT-000 MTEF-KIT-S Standard: 24"-34" (61 to 86.3 cm)
The following parts are included in the rail kit package (see figure below):
1x Right inner rail (A) +2x Outer rails (C) - Bundled
1x Left inner rail (B) + 2x Outer rails (D) - Bundled
10x M6 Standard cage nuts¹ ² and 10x M6 Standard pan-head Phillips screws¹ (E)
2x Phillips100 DEG F.H TYPE-I ST.ST 6-32 X 1/4 screw with a round patch (F)
¹ Other threads are available by special order: M5, 10-32, 12-24.² G-type cage-nut is available by
special order.
Rack Rail Kit Parts
The telescopic rail kit is not included in the system’s package, and can be purchased
separately.
