Nvidia Spectrum-3 SN4000 Series

29
1.
1.
Rear side (FRUs):
2. Front side (ports):
Standard Racks (580-800 mm) Installation Options
Rear side (FRUs):
2. Front side (ports):
Short Racks (430-580 mm) Installation - Side View
Front side (ports):
Rear side (FRUs):
In short racks, the system’s ventilation openings should be framed by the designated
windows in the rails, as shown below.

