Plug in the first power cable.
Plug in the second power cable.
Wait for the System Status LED to turn green.
Check the System Status LEDs and confirm that all of the LEDs show status lights consistent
with normal operation as shown in the figure below. For more information, refer to “LEDs”.
*The figure is for illustration purposes only. The LEDs location and shape may slightly vary in different
systems.
Two Power Inlets - Electric Caution Notifications:
In the SN4700 systems, two power cords are provided for each power supply unit In order to
meet the electrical requirements of various regions. Please make sure to use the cord that
meets the power requirements of your country or region.
The system platform will automatically power on when AC power is applied. There isno
power system. Check all boards, power supplies, and fan tray modules for properinsertion
before plugging in a power cable.
It may take up to five minutes to turn on the system. If the System Status LED shows
amber after five minutes, unplug the system and call your NVIDIA representative for
assistance.
After inserting a power cable and confirming the green System Status LED light is on, make
sure that the Fan Status LED shows green.
If the Fan Status LED is not green, unplug the power connection and check that the fan
module is inserted properly and that the mating connector of the fan unit is free of any dirt
and/or obstacles. If no obstacles were found and the problem persists, call your NVIDIA
representative for assistance.
•
•
Risk of electric shock and energy hazard. The two power supply units are
independent. Disconnect all power supplies to ensure a powered down state inside of
the switch platform.
ACHTUNG Gafahr des elektrischen Schocks. Entferrnen des Netzsteckers elnes
Netzteils spannungsfrei. Um alle Einhieten spannungsfrei zu machen sind die
Netzstecker aller Netzteile zu entfernen.
