System Mounting Options
The systems are shipped with the rail-kits specified in the following table:
System Model Rail Kit
SN2700
SN2700 Static Rail Kit
Optional:
SN2700 Telescopic Rail Kit
SN2410, SN2740 SN2740/SN2410 Static Rail Kit
SN2100, SN2010
The systems are shipped without a rail kit. A designated rail kit can
be purchased separately.
For installation instructions, see SN2100/SN2010 Side by Side
Mounting Rail Kit.
SN2201 SN2201 Tool-Less Rail Kit
SN2700 Static Rail Kit
Part Number Legacy Part Number Rack Size and Rack Depth Range
930-9BRKT-00JC-000 MTEF-KIT-A Short (17”-24”) or Standard (24”-34”)
The following parts are included in the static rail kit (see figure below):
2x Rack mount rails (A)
2x Rack mount brackets (B)
2x Rack mount blades (C)
8x M6 Standard cage nuts¹ ² and 8x M6 Standard pan-head Phillips screws¹ (D)
4x Phillips100 DEG F.H TYPE-I ST.ST 6-32 X 1/4 screws with a round patch (E)
¹ Other threads are available by special order: M5, 10-32, 12-24.² G-type cage-nut is available by
special order.
Rack Rail Kit Parts
If anything is damaged or missing, contact your sales representative at
support@mellanox.com.
