Specifications
SN2700 Series
Feature Value
Mechanical Size:
Standard depth - 1.72” (H) x 16.84” (W) x 27” (D).
43.8mm (H) x 427.83mm (W) x
686.8mm (D).
Short depth - 1.72'' (H) x 16.84'' (W) x 17'' (D).
43.9mm (H) x 428mm (W) x 432mm
(D).
Mounting: 19” Rack mount
Weight: 1 PSU: 10.23kg, 2 PSUs: 11.1kg
Speed: 10/25/40/50/56/100GbE per port
Connector cage: 32 QSFP28
Environmental Temperature: Operational: 0° to 40°C
Non-Operational: -40° to 70°C
Humidity: Operational: 10% - 85% non-condensing
Non-Operational: 10% - 90% non-condensing
Altitude: 3050m
Noise level: 71.6 dB(A)
Regulatory Safety/ EMC: CB, cTUVus, CE, CU, S_Mark, CE, FCC, VCCI, ICES,
RCM, BSMI, KCC, CCC
RoHS: RoHS complaint
Power Supply
AC and DC
Input Voltage: 1x/2x, -127VAC; 50/60Hz 4.5A; 200-240 50/60Hz
2.9A/ 40.5-60VDC 12A/ 192-288VDC (not certified)
-48VDC, Input voltage range (-40) to (-72)VDC
Global Power Consumption:
40GbE/100GbE Models -
Typical power with passive cables (ATIS): 130W
Main Devices CPU: Intel x86 1.40GHz Dual Core
PCIe: 4x Gen2.0
Switch: NVIDIA Spectrum
Memory: 8GB DDR3 RAM, 32G SSD for systems based on
Switch rev. B1 and earlier
8GB DDR3 RAM, 16G SSD for systems based on
Switch rev. B2 and higher
Throughput 6.4Tb/s
