Nylex 719042 - Overview

8 9 10 11 12
13 14 15 16
1
19
2
3
4 5 6 7
18
17
1 2
3
5
8
9
4
7
6
12
10
11
13
OVERVIEW
LCD Monitor
1. SNOOZE / LIGHT button
2. HISTORY button
3. MAX/MIN button
4. RAINFALL button
5. BARO button
6. WIND button
7. INDEX button
8. CLOCK button
9. ALARM button
10. ALERT button
11. DOWN button
12. UP button
13. °C/°F slide switch
14. SCAN button
15. RESET button
16. Battery compartment
17. Alert LED indicator
18.
LCD display with backlight
19. Table stand
Wireless Sensor
1. Rain collector
2. Balance indicator
3. Antenna
4. Wind cups
5. Mounting pole
6. Radiation shield
7. Wind vane
8. Mounting base
9. Mounting claim
10. Red LED indicator
11. RESET button
12. Battery door
13. Screws
