O.S. engine FL-70 - Engine Dimensions and Specifications

44
11.45cc(0.698cu.in.)
27.7mm (1.090 in.)
19.0mm (0.748 in.)
2.300-12.000 r.p.m.
1.1ps/ 11.000 r.p.m.
467g (16.480Z.)
51.5g(1.8oz.)
Displacement
Bore
Stroke
Practical R.P.M.
Power output
Weight
(Silencer including
exhaust header pipe)
THREE VIEW DRAWING Dimension(mm)
Specification
