O.S. engine MAX-15CV-R Series Owner's Instruction Manual

26
15CV-RX EXPLODED VIEW
Not included in 15CV-RX(S)
10
Type of screw
C...Cap Screw M...Oval Fillister-Head Screw
F...Flat Head Screw N...Round Head Screw S...Set Screw
1
C.M2.6x12
2
3
4
5
6
7
8
9
10
11
12
13
14
15
18
16
M.+M2.6x7
17
19
19-1
19-2
M.+M2.6x7
27
15CV-RX ENGINE PARTS LIST
The specifications are subject to alteration for improvement without notice.
No.
Code No.
Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
19-1
19-2
102 Cleaner Body
101,102 Filter Elements (6pcs.)
Super Air Cleaner 102 (W/3 filter elements) [off -road]
Screw Set
Glow Plug No.8
Gasket Set
Crankshaft
Crankshaft Ball Bearing (Rear)
Crankcase
Crankshaft Ball Bearing (Front)
Carburetor Retainer
Carburetor Complete (Type 10C)
Connecting Rod
Piston Pin Retainer(2pcs.)
Piston Pin
Cylinder & Piston Assembly
Heatsink Head
Carburetor Complete (Type 10E-R)
Propeller Nut
Drive Hub
Starting Shaft
Rear Adaptor
No.5 Recoil Starter Assembly
No.5 Recoil Starter Body
No.5 One-way Clutch
Engine Mount Spacer
72403120
72403210
21421200
21514010
21252040
21230020
72403200
71608001
21421300
21501030
22631020
21408000
20810007
21481700
21481020
21286000
21255000
21817000
21806000
21503050
21504600
21313030
73003000
73003100
73003200
72404000
21252050
Crankshaft (For 15CV-RX(S))
