Oase FiltoClear 5000 Manual

EN
17
Product description
Overview
 A
1
Water inlet for the pond water being cleaned
•
Connection G2
2
Opening ring with locking screw for locking the UVC unit head
• It is necessary to open the opening ring in order to remove the UVC unit head.
3
Water outlet for the
cleaned pond water
•
Connection G2
4
UVC unit head with temperature monitor
•
The UVC clarifier shuts down when overheating and automatically turns on again after it has
cooled down
5
Turning valve for switching between water outlet and dirt water outlet
Water filtration and UVC radiation
Cleaning the foam filters
6
Dirt water outlet for the dirt water when cleaning the foam filters
• Connection G2
7
Indicator lamp for checking the function of the UVC clarifier
8
Cleaning handle
•
Pull to compress the foam filters and flush out the dirt particles
9
Filter cover
10
Clamping ring for fastening the filter cover on the container
11
Marking for max. burying depth
12
Container
13
Cleaning rotor, cleans the quartz glass during operation
•
Only for FiltoClear 19000, 31000
14
Foam filter, blue (10
ppi)
15
Foam filter, red (30 ppi)
16
Foam filter, purple (20 ppi)
17
Closing disc for foam filters, is connected with both cleaning rods
18
Cleaning rod, connecting cleaning handle and closing disc
19
Meshed tube, maintaining the distance between the foam filters and the UVC water housing
20
UVC water housing, conveying water to the UVC lamp
21
Spacers that connect the two spacer discs
•
The spacers prevent the foam filters from being compressed by the weight of the foam filters
above them
22
Quartz glass with internal UVC lamp
23
Spacer disc, placed between each pair of foam filters
