- EN -
26
Closing the container
H, I
How to proceed:
• Clean the channel (H 37) around the container rim.
• Grease the lid sealing ring (34) and place flush around the container (38) top edge.
• Press the filter lid (I 8) including the stack of foam filters on the container, if necessary, assist with your own body
weight.
• Place the clamping ring (10) around the container top edge (do not pinch the power cable) and assemble.
• Engage the closing hook (35).
• Push in the safety latch (36).
Cleaning the foam filters
The Easy-Clean function (actuate the cleaning handle and flush with water) allows easy cleaning of foam filters, UVC
unit and UVC water housing.
J, K, L
How to proceed:
• Remove the closing cap from the drain hose or the dirty water drain socket (K 7). Attention: Do not lose the sealing
ring in the cap!
• Turn the function switch (5) counter-clockwise to "Cleaning foam filters" (41).
• Vigurously pull up the cleaning handle (3) several times, then push the handle down against the stop ("pumping"
action).
The foam filters will be rinsed by this action.
• As soon as only clean water appears in the transparent hose connector (20), turn the function switch (5) counter-
clockwise to "Cleaning UVC" (L 42).
The UVC unit and the UVC water housing are flushed.
• As soon as only clean water appears in the transparent hose connector (20), turn the function switch (5) counter-
clockwise to "Filter water" (J 40).
The unit filters the pond water.
• Close the drain hose or the soiled water drain socket (7) using the closing cap (insert sealing ring!) (C 9).
Cleaning the quartz glass tube manually
E, F
WARNING
Possible death or severe injury from hazardous electrical voltage!
• Prior to reaching into the water, isolate (switch off and disconnect) all units/devices used in the water.
• Isolate the device (disconnect from the power supply) before carrying out any work on it.
How to proceed:
• Switch off the filter pump.
• Remove the UVC unit head (Cleaning and maintenance\Removing/inserting the UVC unit head).
• Check the quartz glass tube (F 19) and O ring (32) for damage. Replace, if necessary.
• Clean the quartz glass tube externally using a moist cloth.
• Insert the UVC unit head (Cleaning and maintenance\Removing/inserting the UVC unit head).
• Switch on the filter pump.
• Switch on the UVC unit.
