Oasis Ci 21 - Dimensions for Swimming Pool Heat Pump Unit

2.2 The dimensions for Swimming Pool Heat Pump Unit
OASIS Ci 10
unit：mm
unit：mm
Water inlet
Φ40
Water outlet
Φ40
3
50
100
10
51
767
435
630
4
10
3
96
447
430
868
1163
470
815
Water inlet
Φ40
Water outlet
Φ40
A
100
2.SPECIFICATION
4
OASIS Ci 13
Model
A
OASIS Ci 17
400 470
3
2.SPECIFICATION
2.1 Performance data of Swimming Pool Heat Pump Unit
*** REFRIGERANT : R410A
Rated Heating: Outdoor air temp: 27 , Inlet water temp:26 /28 ℃/24.3℃ ℃ ℃
UNIT
Nominal Heating Power
Input By 50Hz
Range
Nominal Running Current
Input By 50Hz
Range
Power Supply
Compressor Quantity
Compressor
Fan Quantity
Fan Power Input
Fan Rotate Speed
Fan Direction
Noise
Water Connection
Water Flow Volume
Water Pressure Drop(max)
Unit Net Dimensions(L/W/H)
Unit Ship Dimensions(L/W/H)
Net Weight
Shipping Weight
kW
Btu/h
kW
Btu/h
kW
A
W
RPM
dB(A)
mm
3
m /h
kPa
mm
mm
kg
kg
Nominal Heating Capacity
By 50Hz
Range
KW
A
OASIS Ci 17
11.5
39100
4.6～19.5
15640～66300
0.37～3.94
1.6～17.1
230V～/50Hz
1
rotary
1
120
500-900
horizontal
45-56
40
6.6
6
1163×447×868
1210×510×880
82
95
1.72
7.5
OASIS Ci 21
14.3
48620
5.7～24.2
19380～82280
0.46～4.8
2.0～20.9
230V～/50Hz
1
rotary
2
200
400-800
horizontal
46-57
40
8.6
11
1163×470×1275
1210×495×1300
110
125
2.1
9.1
OASIS Ci 25T
17.2
58480
6.7～28.3
22780～96220
0.54～5.57
1.34～9.18
380V/3N～/50Hz
1
rotary
2
200
400-800
horizontal
48-58
40
10
15
1163×470×1275
1210×495×1300
113
131
2.5
4.48
