Diagram 14.1 Diagram 14.2
• Replace side panel onto the cooler. Position the key slot in panel on the screw in the front
fascia, and slide panel downward over locater in moulded base
• Affix 3 screws in position illustrate in (Diagram 14.2).
Diagram 14.3 Diagram 14.4
• Reposition top of Kalix as per (Diagram 14.3)
• Slide top over push buttons, then secure in position via two screws at the back of the cooler.
• Ensure cup dispenser is firmly in position before securing screws.
• Return filter compartment door to its exact position, then replace drip tray to its place.
14. Finally the new filtration system needs to be flushed out of the cooler.
• Turn on mains water supply and connect electrical supply to the cooler.
• First dispense water from the cold side of the cooler for 2 minutes.
• Then dispense water from the cook side of the cooler for 60 seconds.
