• Disassemble parts and remove o-rings from insert and cap.
• Place all filter parts back in sanitization solution for a further 10 minutes.
• Remove all parts from sanitization solution, and rinse thoroughly under a tap.
12. Re-install additional parts
Diagram 13.1 Diagram 13.2
• Using replacement filter media push insert into position.
• Re-assemble filter as shown in (Diagram 13.1).
• Re-attach mounting bracket to filter head.(Diagram 13.2)
Diagram 13.3 Diagram 13.4
