Oasis Mirage - Installing the Water Bottle; Bottle Installation Steps

The Mirage can use 3 or 5
gallon water bottles. This
unit also easily converts to
a direct water line. Please
see page 7 for instructions
on installing this unit direct
to a water line and ltration
system.
Installing the Water Bottle
oasiscoolers.com Page5
IMPORTANT:Alwayswashyourhandsrstbeforehandlingwaterbottle!Cleanthetopofthewaterbottle
withacleancloth.Waterbottlescanbepurchasedfromyourlocalretailer.
1. Makesurethelowerdoor(bottlestoragecompartment)isopen.Thewaterpumpcannotoperateas
longasthedoorisintheopenposition.
2. Removetheprotectivelabelfromthetopofthebottle.DonotremovetheBottleCap.s
3. Mostwaterbottleshaveapuncturablemembraneinthetopcap.Topuncturethemembrane,insert
thestrawintothecapandpushdownwarduntilthemembraneopens.Insertthestrawallthewayinto
thebottleuntilthebottomofthestrawtouchesthebottomofthewaterbottle.NOTE:Thewaterbottle
drinkingstrawfeaturesanexclusivetelescopicdesignforusewitheither18.9L(5gal)and11.4L(3gal)
waterbottles.(SeeFig.1&Fig.2)Toadjustthelengthofthewaterbottledrinkingstraw,holdtheupper
portionofthestrawandsimplypull/pushthelowerportionofthestrawtothedesiredlength.
4. Toattachthewater
bottlestrawontothe
neckofthewater
bottle,makesurethe
handleispositioned
“horizontally”and
pressrmlyontothe
topofthebottleneck.
(SeeFig.3)Whenthe
handleisinthe“verti-
cal”(locked)posi-
tion,(SeeFig.4)itis
possibletolift/carry
thewaterbottle(the
BottleCapmustbe
inplacetolift).How-
ever,wheninstalling
the18.9L(5gal)water
bottleinsidethestor-
agecompartment,the
handlemustbeinthe
“horizontal”position.
(SeeFig.3)
