Converting to Direct Water Line (bottleless water option)
1. Yourcoolercomessetupfor3gal.(11.4L)or5gal.(18.9L)bottlebottomloadasshown
ingure“A”.
2. Disconnectthebottlesiphonfromthedoorbypullingthehandleawayforthedoor,as
shownbythearrowdirectioningure“A”
3. Disconnectthewatersupplytubefromthesiphoncapelbowasshownifgure“B”,see
instructionsbelow
Water tube to Elbow connect and
disconnect procedures
A
B
C
oasiscoolers.com Page7
4. Afterdisconnectingthesiphon,storeinasafeplaceforfutureuse.Thesiphonassembly
willtintheopenspacebythecondenserasshowningure“C”
5. ConnecttheStemElbowthatwassuppliedwithyourcoolertothewatersupplytubeas
showningureD.TheStemElbowisa¼stemconnectionthatwillbestandardforyour
ltersystemsetuplaterintheseinstructions
D
