Oasis PG8ACSL User Manual

PLACE THIS EDGE AGAINST WALL
ALIGN THIS EDGE WITH LEFT EDGE OF COOLER TOP
USE THIS TEMPLATE TO MARK THE
HOLE LOCATION ON COOLER TOP
3-1/4”
from
side
2-1/8”
from
back
Mark this center point on the
top. Remove the top from the
cooler. Then create a 7/8”
diameter hole through the top
at the marked center point
(step drill bit or punch die).

Oasis PG8ACSL Specifications

General

Brand	Oasis
Model	PG8ACSL
Category	Water Dispenser
Language	English
