Go to Step 5 “Final steps for both product families:”
The tee and tube to the Versafiller are packaged with the PWEBF
unit. One branch of the tee will supply the valve on the dummy unit,
the other branch of the tee will connect to the Versafiller.
If a filter is being installed, cut a piece of tubing about 3” long to
insert flow switch right after filter and before tee. This allows
Versafiller counter to accurately calculate amount of water passing
through filter.
Tube to connect valve
on dummy unit
Tube to connect
Versafiller
Tube to connect chilled
water to dummy unit
and Versafiller
To Next Page
