Oasis PG8ACSL - Page 14

2. Disconnect tubing from the
elbow on the valve.
3. Using the 38” piece
of tubing provided,
cut 6” and install it
on the end of the
TEE. Install the
remaining tubing
onto the branch of
the TEE. Connect
the other end of the
TEE to the tank
outlet tubing (tube
that was
disconnected from
the elbow).
32” tubing
6” tubing
4. Route the TEE and
tubing under the
waste drain and
connect the 6” length
to the water valve
elbow.
TEE
Go to Step 5 “Final steps for both product families:”
Water
valve
elbow
Section 3: Installation: For the P8AC Version: Versacooler II
