Ocean Digital WR-03 - Location of Controls; Device Ports and Indicators

Location of Controls
1. 2.8'' TFT color screen
2. Infrared remote sensor
3. 3.5mm antenna input socket
Two types of antenna are supplied with the radio. One is wire
type and the other is the rod antenna. Apply one of them to get
the best result on the reception of DAB and FM radio
4. 3.5 mm audio out socket
Connect external powered speakers with 3.5 mm plug or RCA
adaptor with 3.5mm plug
5. Optical Out
Digital optical output connection
6. DC IN socket
Connect with the power adaptor supplied in the package
7. Power ON/OFF switch
1 2
3 4 5 6 7
- 01 -
