Appendix A
Bulb Replacement
Overview
To order replacement bulbs for the HL-2000, consult the Parts List.
WARNING
Before replacing the bulb in the HL-2000, disconnect the lamp from your power
source and allow the unit to cool for at least twenty minutes, if necessary.
Identifying the Bulb Type
► Procedure
Perform the steps below to identify the bulb type:
1. Unplug the power connector from the power socket on the HL-2000.
2. Loosen the screws on the rear of the unit with the provided 2.5mm Allen wrench.
3. Remove the backside of the HL-2000 and remove the electronics board from the HL-2000, taking
particular care not to disconnect the fan wires.
4. Remove the screws from the bottom plate of the unit with the provided 1.3mm Allen key.
000-10000-050-02-0505 7
