REGULATORS
DELTA 4 SECOND STAGE
© 2002 Design, 2005
PG-16
OCEANIC® Product Service Guide
Doc. 12-2803-r02 (10/3/10)
1c 6949.23 RING, COVER (METAL)
6930.07 RING, COVER (BK)
2c 6931.07 COVER, FRONT (BK)
6931.18 COVER, FRONT (YL)
3b 6932.11 COVER, INNER FRONT (BL)
6932.18 COVER, INNER FRONT (YL)
6932.34 COVER, INNER FRONT (BK)
4b 5236 DIAPHRAGM
5c 5248.07 ASSEMBLY, HOUSING
6c 5234.07 COVER, EXHAUST
7b 6326 VALVE, EXHAUST
8a 1978.07 WRAP, TIE
9b 4485.07 MOUTHPIECE
10a 2.010 O-RING, ORIFICE
11c 6621 ORIFICE
12c 6956 COUPLING (SWIVEL ONLY)
13b 3.906 O-RING, COUPLING
14a 4340 SEAT, POPPET
15c 4333 POPPET
16c 4593 SPRING, POPPET
17c 5254 ARM, LEVER
18a 5117 WASHER
19b 4335 SPACER
20a 4336 NUT, LOCK
21c 5244 SHAFT, BALANCE
22b 4969 WASHER, SNAP
23a 2.004 O-RING, BALANCE SHAFT
24c 5245 TUBE, ADJUSTMENT
25b 2.016 O-RING, ADJUSTMENT
TUBE
26c 4971 PAD, SPRING
27c 4589 SPRING, ADJUSTMENT
28c 6684 FOLLOWER, PISTON SPRING
29c 6685 SHAFT, ADJUSTMENT
30b 2.107 O-RING, STEM
31b 5054 WASHER, THRUST
32c 6332 NUT, PACKING
33c 6971.18 KNOB, ADJUSTMENT (BK/YL)
6971.29 KNOB, ADJUSTMENT (BK/GY)
34c 4787.2 SCREW, ADJUSTMENT KNOB (BK)
35c 6924 SWITCH, VENTURI
36b 2.009 O-RING, VENTURI SWITCH
37b 5251 RING, SWITCH RETAINING
38c 40.2120.030 ASSEMBLY, SWIVEL HOSE (Swivel Version 1 &
2 ONLY)
39a 6959 WASHER, LP HOSE (Swivel Version 1 ONLY)
40a 6968 O-RING, LP HOSE (Swivel Version 1 & 2
ONLY)
41b 3.903 O-RING, LP HOSE (First Stage End)
42c 6948 HOSE PROTECTOR (Swivel Version 1)
43c TBD HOSE PROTECTOR (Swivel Version 2)
44c 6438.07 HOSE PROTECTOR (Non-Swivel Version)
45c 40.2100.030 HOSE (Non-Swivel), MAXFLO, 30" (BK)
46c TBD COUPLING (NON-SWIVEL ONLY)
47c 7026 COUPLING (Swivel Version 2)
N/S 40.6162 KIT, SERVICE PARTS (includes all Bold
items)
Dia.
No. Part # Description
Dia.
No. Part # Description
