REGULATORS
DELTA 4 SECOND STAGE
© 2002 Design, 2005
PG-2
OCEANIC® Product Service Guide
Doc. 12-2803-r02 (10/3/10)
CONTENTS
TROUBLESHOOTING ..................................................................................................................................................................2
DISASSEMBLY PROCEDURE ..................................................................................................................................................... 3
REASSEMBLY PROCEDURE ...................................................................................................................................................... 7
FINAL TUNING AND TESTING .................................................................................................................................................. 11
PARTS LIST AND EXPLODED VIEW DIAGRAM ...................................................................................................................... 15
SPECIFICATIONS
Torques
P/N 6956 Coupling 100 to 120 in-lbs
P/N 4787.2 Screw 4 to 5 in-lbs
P/N 6332 Packing Nut 11 to 13 in-lbs
LP Hose 50 to 60 in-lbs
GENERAL PROCEDURES
REFER TO ...............................................................................................................................................................DOC. 12-2202
TOOLS REQUIRED
Standard Tools
Inch pounds Torque Wrench
3/32” Hex Key Socket
5/8” Open End Wrench
3/4” Open End Wrench
15/16” Open End Wrench
Standard Screwdriver - small
Cotton Swab
Specialty Tools
P/N 40.3362 Poppet Tool
P/N 40.4400 Retaining Ring Tool
P/N 40.9315 Intermediate Press. Gauge
P/N 40.9520 O-ring Tool Kit
P/N 40.9650 Universal FRONT COVER Tool
Oceanic approved Halocarbon Based Lubricant (See
General Procedure Doc. 12-2202 for approved list)
Opening Effort IP = 138 psi (9.5 bar)
1. Leak with ADJUSTMENT KNOB turned fully out, clockwise.
2. No leak with knob turned in, counter clockwise, 1.5 turns.
3. Minimum effort with no leak = 1.2 inches of H
2
O, or less.
