TECHNICAL DATA
In- and outputs
32
Phono
RIAA equalization tolerance
0.3 dB/15 Hz – 20 kHz
Corner frequency – subsonic filter
15 Hz/-3 dB
Signal-to-noise ratio
-75/-84 dB/with IN 2 MC input
Input sensitivity
250 µV/600 µV/with IN 2 MC input
Input sensitivity, gain and input resistance depend on input module
Gain – MC Gain Low - Pre Out
Gain Low: 70 dB, Med: 77 dB, High: 83 dB
Gain – MC Gain High - Pre Out
Gain Low: 79 dB, Med: 86 dB, High: 92 dB
General data
Power consumption
35 – 60 W
Weight, preamplifier/power supply
10 kg/3.8 kg
Supplied accessories
Power cable, remote control
Dimensions of preamplifier (overall)
Width x height x depth = 462 x 130 x 480 mm
Dimensions of power supply (overall)
Width x height x depth = 110 x 90 x 277 mm
