2
AD194 27/03/07 - 88014542D
1 Choose the position
The remote control will be installed against an internal partition, about
1.5 m from the floor in a judiciously choosen "reference" room.
Positions to be avoided
Enclosed, exposed to solar radiation, heated by a flue duct, exposed
to cold or hot air currents from air ducts, close to an open fireplace, a
heat source (television), behind a curtain.
2 Attachment
Carefully release the lugs on the front panel from the
ribs in the box using a screwdriver.
Remove the cover.
Drill 2 holes with a Ø of 6 mm. Put the rawplugs in place. Secure
the box using the 2 screws provided.
#
8800N036B
8801N338
MODE
1
MODE
Ø 6mm
2
2
3
8801N339
