8. Examine the block surface for wear. The wear pattern should be centered
on the face of the block.
9. If the block needs to be adjusted, loosen the socket head bolt on the
housing.
10. To move the block left or right, adjust the torque bushing with the ¾"
wrench to tighten the socket head bolt on the housing. To move it up or
down, adjust the lock nut with the 1¼" wrench.
11. Tighten the socket head bolt on the housing.
12. Repeat this process until the wear mark is centered on the concave face
of the lubricity block.
Up / DownLeft / Right
