EN-6 Ranger™ Count 3000 Series
The colored LED indicators on the left side of the control panel are used in Checkweigh mode
(section 3.5) and will light up according to the following rules:
(Red) Loads > Upper limit
(Green) Loads ≥ Lower limit and ≤ Upper limit
(Yellow) Loads < Lower limit
Figure 3-3. Below view of Ranger Count 3000
Power Input
Weigh Below
Access
Lock Switch
RS232 and Option
Interface Port
(below cover)
