9、Technical parameters of system
Model TCS-C18/C26 TCS-C32 TCS-C64 TCS-C80
Rocker
feedback
system
Radio
Frequency range 400-470 MHz
Transmission rate 9600 Bit/s
Transmitting power ≤10 mW
frequency tolerance
＜4 ppm
Track restraint
＞50 dB
Modulation mode FSK / GFSK (Gauss frequency Shift Keying)
Channel spacing 25 KHz
Receiving sensitivity -115 dBm
Verification mode CRC-1TM
Technical data
Transmitter weight (kg)
1.4 (excluding
battery)
2.0 (excluding
battery)
3.0 (excluding
battery)
2.2 (excluding
battery)
Transmitter size (mm)
254x130x168
(L x W x H )
317x162x181
(L x W x H )
418x216 x 194
(L x W x H )
317x162 x 181
(L x W x H )
Housing material High-strength engineering plastics
Receiver weight (kg) 2
Receiver size (mm)
248 x 206 x 75mm（CANBUS type）
310 x 206 x 103（relay type）（Large-sized） (L x W x H)
310 x 375 x 103（relay type）（D type）
Receiver installation size
(mm)
186 x 88.5
Receiver installation
hole diameter (mm)
Φ6
Operation
temperature (℃)
-25 — +70
Operation
humidity
0 — 97%, anti-condensation
Standard and grade
Safety standard
JB/T8437-1996
EN13849 grade D
Radio Transmitter Model Approval Certificate

