This document describes the ROB 4600 Robot Vacuum Cleaner, a device designed for automated floor cleaning. It functions as a robot aspirateur et laveur de sol, a Saug-Wisch-Roboter, and an Aspirapolvere e lavapavimenti robot, indicating its capability for both vacuuming and mopping.

Function Description

The ROB 4600 is a versatile robot vacuum cleaner that can operate in various cleaning modes:

Systematic Mode: For optimal room cleaning, the appliance uses a gyroscope-controlled navigation system, cleaning in a zigzag pattern if room conditions allow.
Spot Mode: The appliance moves from the center of a designated area in an ever-widening circle to clean a specific spot.
Corner Mode: Placed against a wall, the appliance moves along the walls to clean corners and edges.
Wiping Function: The device can be used for wet cleaning by attaching a water tank with a cleaning fleece. It's crucial to start the appliance immediately after attaching the water tank to prevent damage to the floor from dripping water.
Scheduled Cleaning: Users can set a schedule for the appliance to switch on at a certain time on selected days. This feature should not be used with the mopping function to avoid water damage to floor coverings.

The appliance automatically switches to a different cleaning mode if it detects that another mode would achieve a better cleaning effect. It also automatically returns to the charging station when the battery capacity drops to about 15% or when the user presses the designated button.

Important Technical Specifications

Model: PC-BSR 3108
Net Weight: Approx. 2.8 kg
Protection Class: II
Power Supply Unit:
- Input: AC 100-240 V, 50/60 Hz, 0.4 A
- Output: DC 19V, 600 mA
Rechargeable Battery: 14.4V, 2600 mAh Li-Ion
Running Time: Approx. 2 hours
Charging Time: Approx. 6 hours
WLAN:
- Supported Network: 802.11b/g/n
- Maximum Radio-Frequency Power Transmitted: 100 mW
- Frequency Range: 2.4 GHz
- Channels: 1-13
- Supported Wi-Fi Protected Access: WPA/WPA2
Storage Temperature: 10°C to 20°C

Usage Features

The ROB 4600 can be operated via both a remote control and a smartphone app ("Smart Life - Smart Living").

Remote Control Operation:

On/Off: Briefly press the power button to switch on. Press again to switch to standby. Hold for about 4 seconds to enter sleep mode.
Mode Selection: Use the "MODE" button to cycle through cleaning modes (Systematic, Spot, Corner).
Start/Stop: The ►II button starts or stops the appliance from sleep mode and confirms settings.
Charging Station Search: Press the button to send the appliance back to the charging station.
Suction Power Adjustment: Increase suction power using the designated button. Note that increased power shortens battery life (approx. 10-15% increase in consumption).
Directional Control: Use arrow buttons to manually move the appliance forward, right, backward, or left.
Scheduled Cleaning: Set a cleaning schedule for specific days and times.

Smartphone App Operation ("Smart Life - Smart Living"):

Installation: Download the "Smart Life - Smart Living" app from Google Play or the App Store.
Registration: Create a user account, enter email, get a verification code, and set a password.
Device Pairing:
- General Connection Mode (Wi-Fi Quick Connection): Select "SMALL HOME APPLIANCE" then "ROBOT VACUUM" in the app. Enter Wi-Fi password, reset the device by holding the button for 3-5 seconds until it beeps and flashes quickly. Confirm reset and select "Wi-Fi Quick Connection".
- Bluetooth Connection Mode: Turn on Bluetooth on the phone, hold the button for 3 seconds until the device beeps and flashes quickly. Confirm the indicator is blinking in the app.
- Compatible Connection Mode (AP Mode): If general connection fails, use this mode. Reset the device, then select "Hotspot Network" in the app and connect to the device's Wi-Fi hotspot.
Remote Control via App: Once connected, all appliance functions can be accessed via the app.
Planned Cleaning: Set cleaning schedules through the app, including start times and repetitions.
Other Operations: The app allows for additional functions such as selecting suction level, viewing cleaning records, and locating the robot.

General Usage Notes:

Ensure sensors are clean before each use to prevent falls down stairs.
Clear the floor of any objects that could obstruct brushes, get caught in the nozzle, or stop the appliance.
Remove items that could be knocked over (vases, lamps).
Ensure cables, cords, or fringes are not accessible to the appliance.

Maintenance Features

Regular maintenance is crucial for the ROB 4600's performance and longevity.

Safety First: Always switch off the appliance before maintenance or cleaning. Never immerse it in water.
Housing Cleaning: Clean with a soft, dry cloth without additives.
Sensor Cleaning: Carefully clean sensors (10/14/17) with a dry soft cloth.
Dust Container and Filter Cleaning:
- Empty the dust container after and before each use for good performance.
- Remove the water tank (if attached), then remove the dust container by pressing the lock.
- Fold the dust container apart and lift the HEPA filter cover.
- Pull out the HEPA filter and clean it by gently tapping.
- Do not use a brush to clean the HEPA filter as it can damage the filter material.
- Empty the dust container over a dustbin.
- Clean the dust container under running water with a soft brush.
- Allow the dust container to air dry completely, away from direct sunlight.
- Reinsert filters only when completely dry.
- Reassemble the dust container and click it back into place.
- It is recommended to replace the HEPA filter once a year.
Side Brush Cleaning/Changing:
- Clean with clear water; do not use additional cleaning agents.
- If worn or defective, replace them. Pull upwards to remove.
- When reattaching, ensure correct alignment with (R) and (L) markings and that they engage with a "click".
Floor Brush Cleaning:
- Remove the cover by pressing the latches and pulling the cover upwards.
- Pull the floor brush upwards from the side with the rubber bearing.
- Clean any hair or dirt from the floor brush.
- Reinsert the floor brush, square nose first.
- Put the cover back on until it clicks into place.
Cleaning Fleece Cleaning:
- After removing from the water tank, wash at 30°C with a little detergent.
- Dry by hanging on a clothesline; do not bleach or iron.
- Reattach to the water tank once dry.
Battery Disposal: The appliance contains a rechargeable battery. Remove the two screws on the battery cover, disconnect the connector, and remove the battery. Dispose of batteries/rechargeable batteries at designated collection points, not with household waste.
Appliance Disposal: Electrical equipment should not be disposed of with domestic waste. Return to collection points for recycling.

Storage:

Clean and dry the appliance completely.
Store in original packaging if not used for a long time.
Store out of reach of children, in a well-ventilated and dry place.
Storage temperature should be between 10°C and 20°C.
Recharge the battery every 4 to 6 weeks if not used for a long time, as it constantly discharges even when off.
