6. When you cannot see the top edge nor
boom edge of the jammed paper move the
paper foward in the direcon of the arrow.
7. When you can see the boom edge of the
jammed paper. Raise the two blue jam release
levers of the fuser unit [A + B] and slowly pull
out the jammed paper.
Note: Aer removing paper jammed in the fuser
unit, print a Menu Map (Refer to ‘Prinng a
Menu Map’ on page 11) or print blank pages
repeatedly to use up toner that may remain
un-fused in the fuser unit.
8. When the jammed paper winds around the
transfer roller. Push (one blue) lock lever in the
direcon of the arrow.
9. Hold the transfer roller by its le rotang
sha and remove it. When it is removable, li
the gear at the right side of the fuser
simultaneously. Pull out the jammed paper
aached.
10. Pull the (two) blue jam release levers forward.
11. Place the image drum back into the printer.
Note: When toner clings to the transparent lm
under the image drum, wipe it o with so ssue
paper.
12. Close the top cover.
