44951501TH Rev.2
8-15
Oki Data CONFIDENTIAL
8. CONNECTION DIAGRAMS
(5) Waste toner sensor PCB
SNS
A
K
C
E
(6) Color adjustment sensor PCB
SNS
CN115
C
E
A
K
(7) Soft Power SW
1
4
4471169922
P6A
CN1
2
244711699
FGZA2
LED501
R501
SW501
