44951501TH Rev.2
8-18
Oki Data CONFIDENTIAL
8. CONNECTION DIAGRAMS
(11) Transfer belt unit
Fuse
Transfer belt unit (for consumables)
Transfer belt unit
Relay PCB
Contact point
Contact point
Fuse
