44951501TH Rev.2
3-7
Oki Data CONFIDENTIAL
3. INSTALLATION
(5) Slide the locks of the (four) toner cartridges to the left to lock the toner cartridges.
(6) Close the top cover.
Lock (blue)
(3) Fan the edges of paper stack and align the edges of the stack on a level surface.
Loading paper in the paper cassette
(1) Pull out the paper cassette.
Note! Do not remove the rubber from the plate.
(2) Adjust the paper stopper and the paper guide to the size of the paper to be loaded
and x them rmly.
Plate
Paper guide
Paper stopper
To Next Page
