Installing upgrades > 78
H
ARD
DISK
DRIVE
The optional internal hard disk drive (HDD) enables collating of
printed pages and can be used to store overlays and macros,
fonts, and secure or proof documents waiting to be printed.
Installation takes a few minutes, and requires a medium size
cross-head (philips type) screwdriver.
1. Switch the printer off and disconnect the AC power cable.
2. Press the cover release and open the printer’s top cover
fully.
3. Lift the front cover latch and pull open the front cover.
4. Remove the screw (1) securing the right-hand side cover.
WARNING!
If the printer has been powered on recently, the fuser
will be hot. This area is clearly labelled. Do not touch.
1
