12. Lower the top cover but do not press down to
latch it closed yet. This will protect the drums
from excessive exposure to room lighng while
you check the remaining areas for jammed
sheets.
13. Open the rear exit tray and check for a sheet
of paper in the rear path area.
Rear Exit Tray Path Area
14. Pull out any sheets found in this area.
15. If the sheet is low down in this area and dicult
to remove, it is probably sll gripped by the fuser.
In this case raise the top cover, reach around and
press down on the fuser pressure release lever.
16. If you are not using the rear exit tray, close it
once any paper has been removed from this area.
7
