59 – C910 Troubleshooting
3. Carefully remove any paper on the belt.
4. If paper is jammed in the fuser unit, push the lock lever (3)
in the direction shown to release the unit.
Holding the fuser unit (4) by the handle, lift it out of the
printer and place it on a flat surface.
WARNING!
Be careful not to touch the fuser unit which may be
hot after printing. If the fuser unit is hot, wait until it
cools before attempting to remove any jammed
paper.
4
3
To Next Page
