Remove 3 screws holding the top cover.
2 in the front – 1 at right and one 1 left,
facing down to the frame.
3
rd
screw is at rear, facing down into the
frame.
There are 4 tabs holding the top cover to
the toner cartridge separators. Disengage
the 4 tabs and lift the top cover off.
Open the paper jam door and remove it by
gently spreading left side hinge pin and
removing the door from the frame.
